IGBT管-IGBT模塊
IRG4PSC71U
電氣特性 Features
- 超高速(8-30kHz)IGBT模塊
- Vces: 600V
- Ic@100℃: 60A
- Vce(ON)@25℃(typ): 1.67V
更新于 2025-12-06FGA30N60LSDTU
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 60 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Through Hole |
| Rad Hard: | No |
IHW20N65R5XKSA1
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 650 V |
| Maximum Continuous Collector Current: | 20 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Through Hole |
| Operating Temperature: | -40 to 175 ℃ |
| Rad Hard: | No |
IRG4BH20K-L
電氣特性 Features
- 超高速(8-30kHz)IGBT模塊
- Vces: 1200V
- Ic@100℃: 5.0A
- Vce(ON)@25℃(typ): 3.17V
IRG7PH42UPBF
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 1200 V |
| Maximum Continuous Collector Current: | 90 A |
| Maximum Gate Emitter Voltage: | ±30 V |
| Mounting: | Through Hole |
| Rad Hard: | No |
IRGP4620DPBF
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 32 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Through Hole |
| Operating Temperature: | -40 to 175 ℃ |
| Rad Hard: | No |
STGW39NC60VD
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 80 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Through Hole |
| Rad Hard: | No |
FGA40N65SMD
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 650 V |
| Maximum Continuous Collector Current: | 80 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Through Hole |
| Rad Hard: | No |
IRGC35B120KB
電氣特性 Features
- 超高速(8-30kHz)IGBT模塊
- Vces: 1200V
- Vce(ON)@25℃(typ): 2.4V
IRG7PH35UD1PBF
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 1200 V |
| Maximum Continuous Collector Current: | 50 A |
| Maximum Gate Emitter Voltage: | ±30 V |
| Mounting: | Through Hole |
| Rad Hard: | No |
STGD6NC60HDT4
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 15 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
IRG4PC40K
電氣特性 Features
- 超高速(8-30kHz)IGBT模塊
- Vces: 600V
- Ic@100℃: 25A
- Vce(ON)@25℃(typ): 2.10V
IKB20N60H3ATMA1
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 40 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Surface Mount |
IRGB30B60KPBF
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 78 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Through Hole |
| Rad Hard: | No |
IHW30N160R2
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 1600 V |
| Maximum Continuous Collector Current: | 60 A |
| Maximum Gate Emitter Voltage: | ±25 V |
| Mounting: | Through Hole |
