IGBT管-IGBT模塊
AUIRGP50B60PD1E
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 75 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Through Hole |
| Rad Hard: | No |
更新于 2025-12-06STGWT40H65FB
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 650 V |
| Maximum Continuous Collector Current: | 80 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Through Hole |
| Operating Temperature: | -55 to 175 ℃ |
| Rad Hard: | No |
NGTB15N135IHRWG
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 1350(Min) V |
| Maximum Continuous Collector Current: | 30 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Through Hole |
| Operating Temperature: | -40 to 175 ℃ |
| Rad Hard: | No |
IRG4BC30FD1PBF
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 31 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Through Hole |
| Rad Hard: | No |
STGB10NC60KDT4
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 20 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
IKB06N60T
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 12 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Surface Mount |
IKQ100N60TAXKSA1
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 160 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Through Hole |
| Operating Temperature: | -40 to 175 ℃ |
| Rad Hard: | No |
IRG4BC40U
電氣特性 Features
- 超高速(8-30kHz)IGBT模塊
- Vces: 600V
- Ic@100℃: 20A
- Vce(ON)@25℃(typ): 1.72V
FGD3245G2_F085
.jpg)
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 480 V |
| Maximum Continuous Collector Current: | 23 A |
| Maximum Gate Emitter Voltage: | ±10 V |
| Mounting: | Surface Mount |
| Operating Temperature: | -40 to 175 ℃ |
| Rad Hard: | No |
IRGB4607D
電氣特性 Features
- 超高速(8-30kHz)IGBT模塊
- Vces: 600V
- Ic@100℃: 7.0A
- Vce(ON)@25℃(typ): 1.75V
IRGP4650DPBF
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 76 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Through Hole |
| Operating Temperature: | -55 to 175 ℃ |
| Rad Hard: | No |
GT40QR21(STA1,E,D)
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 1200 V |
| Maximum Continuous Collector Current: | 40 A |
| Maximum Gate Emitter Voltage: | ±25 V |
| Mounting: | Through Hole |
| Rad Hard: | No |
IKB10N60T
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 20 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Surface Mount |
| Rad Hard: | No |
HGT1S20N60C3S9A
電氣特性 Features
| Configuration: | Single |
| Channel Type: | N |
| Maximum Collector Emitter Voltage: | 600 V |
| Maximum Continuous Collector Current: | 45 A |
| Maximum Gate Emitter Voltage: | ±20 V |
| Mounting: | Surface Mount |
IRG7CH35UEF
電氣特性 Features
- 超高速(8-30kHz)IGBT模塊
- Vces: 1200V
- Vce(ON)@25℃(typ): 1.90V
