其它場(chǎng)效應(yīng)管
BF1108R,215
電氣特性 Features
| Configuration: | Single Dual Gate |
| Maximum Drain Source Voltage: | 3 V |
| Maximum Continuous Drain Current: | 10 mA |
| Maximum Gate Source Voltage: | 7 V |
| Maximum Drain Gate Voltage: | 7 V |
| Operating Temperature: | -65 to 150 ℃ |
| Mounting: | Surface Mount |
更新于 2025-12-05ATF-58143-TR1G
電氣特性 Features
| Configuration: | Single Dual Source |
| Maximum Drain Source Voltage: | 5 V |
| Maximum Continuous Drain Current: | 100 mA |
| Maximum Gate Source Voltage: | 1 V |
| Maximum Drain Gate Voltage: | -5 to 1 V |
| Operating Temperature: | -65 to 150 ℃ |
| Mounting: | Surface Mount |
| Rad Hard: | No |
ATF-501P8-BLK
電氣特性 Features
| Configuration: | Single Dual Source |
| Maximum Drain Source Voltage: | 7 V |
| Maximum Continuous Drain Current: | 1000 mA |
| Maximum Gate Source Voltage: | 0.8 V |
| Maximum Drain Gate Voltage: | -5 to 1 V |
| Operating Temperature: | -65 to 150 ℃ |
| Mounting: | Surface Mount |
| Rad Hard: | No |
ATF-521P8-TR2
電氣特性 Features
| Configuration: | Single Dual Source |
| Maximum Drain Source Voltage: | 7 V |
| Maximum Continuous Drain Current: | 500 mA |
| Maximum Gate Source Voltage: | 1 V |
| Maximum Drain Gate Voltage: | -5 to 1 V |
| Operating Temperature: | -65 to 150 ℃ |
| Mounting: | Surface Mount |
| Rad Hard: | No |
TIM4450-8UL
電氣特性 Features
| Configuration: | Single |
| Maximum Drain Source Voltage: | 15 V |
| Maximum Continuous Drain Current: | 7000 mA |
| Maximum Gate Source Voltage: | -5 V |
| Operating Temperature: | -65 to 175 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
TIM7785-45SL
電氣特性 Features
| Configuration: | Single |
| Maximum Drain Source Voltage: | 15 V |
| Maximum Continuous Drain Current: | 20000 mA |
| Maximum Gate Source Voltage: | -5 V |
| Operating Temperature: | -65 to 175 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
TIM6472-45SL
電氣特性 Features
| Configuration: | Single |
| Maximum Drain Source Voltage: | 15 V |
| Maximum Continuous Drain Current: | 20000 mA |
| Maximum Gate Source Voltage: | -5 V |
| Operating Temperature: | -65 to 175 ℃ |
| Mounting: | Screw |
TIM4450-16UL
電氣特性 Features
| Configuration: | Single |
| Maximum Drain Source Voltage: | 15 V |
| Maximum Continuous Drain Current: | 14000 mA |
| Maximum Gate Source Voltage: | -5 V |
| Operating Temperature: | -65 to 175 ℃ |
| Mounting: | Screw |
TIM6472-60SL
電氣特性 Features
| Configuration: | Single |
| Maximum Drain Source Voltage: | 15 V |
| Maximum Continuous Drain Current: | 20000 mA |
| Maximum Gate Source Voltage: | -5 V |
| Operating Temperature: | -65 to 175 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
ATF-501P8-TR2
電氣特性 Features
| Configuration: | Single Dual Source |
| Maximum Drain Source Voltage: | 7 V |
| Maximum Continuous Drain Current: | 1000 mA |
| Maximum Gate Source Voltage: | 0.8 V |
| Maximum Drain Gate Voltage: | -5 to 1 V |
| Operating Temperature: | -65 to 150 ℃ |
| Mounting: | Surface Mount |
| Rad Hard: | No |
TIM5964-30UL
電氣特性 Features
| Configuration: | Single |
| Maximum Drain Source Voltage: | 15 V |
| Maximum Continuous Drain Current: | 18000 mA |
| Maximum Gate Source Voltage: | -5 V |
| Operating Temperature: | -65 to 175 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
CLY29-10(P)
電氣特性 Features
| Configuration: | Single |
| Maximum Drain Source Voltage: | 14 V |
| Maximum Continuous Drain Current: | 700 mA |
| Maximum Gate Source Voltage: | -6 V |
| Maximum Drain Gate Voltage: | 16 V |
| Operating Temperature: | -65 to 175 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
VMMK-1218-BLKG
電氣特性 Features
| Configuration: | Single |
| Maximum Drain Source Voltage: | 5 V |
| Maximum Continuous Drain Current: | 100 mA |
| Maximum Gate Source Voltage: | 1 V |
| Maximum Drain Gate Voltage: | -5 to 1 V |
| Operating Temperature: | N/A to 150 ℃ |
| Mounting: | Surface Mount |
| Rad Hard: | No |
TIM1112-2
電氣特性 Features
| Configuration: | Single |
| Maximum Drain Source Voltage: | 15 V |
| Maximum Continuous Drain Current: | 2600 mA |
| Maximum Gate Source Voltage: | -5 V |
| Operating Temperature: | -65 to 175 ℃ |
| Mounting: | Screw |
| Rad Hard: | No |
TGF4240-SCC
電氣特性 Features
| Maximum Drain Source Voltage: | 12 V |
| Maximum Gate Source Voltage: | 0 V |
| Operating Temperature: | -65 to 200 ℃ |
| Mounting: | Surface Mount |
| Rad Hard: | No |
