| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 350 V |
| Maximum DC Collector Current: | 0.5 A |
| Minimum DC Current Gain: | 25@50mA@10V|30@100mA@10V|15@250mA@10V|5@500mA@10V |
| Maximum Operating Frequency: | 10(Min) MHz |
| Maximum Collector Emitter Saturation Voltage: | 1@10mA@100mA|2.5@25mA@250mA|10@100mA@500mA V |
| Maximum Collector Base Voltage: | 375 V |
| Operating Temperature: | -65 to 150 ℃ |
| Maximum Power Dissipation: | 20000 mW |
| Mounting: | Through Hole |
| Rad Hard: | No |
| Type: | NPN|PNP |
| Pin Count: | 6 |
| Maximum Collector Emitter Voltage: | 65 V |
| Maximum DC Collector Current: | 0.1 A |
| Minimum DC Current Gain: | 200@2mA@5V |
| Maximum Operating Frequency: | 250(Typ) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.3@0.5mA@10mA|0.65@5mA@100mA V |
| Maximum Collector Base Voltage: | 80 V |
| Operating Temperature: | -65 to 150 ℃ |
| Maximum Power Dissipation: | 250 mW |
| Mounting: | Surface Mount |
| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 140 V |
| Maximum DC Collector Current: | 0.6 A |
| Minimum DC Current Gain: | 60@1mA@5V|60@10mA@5V|20@50mA@5V |
| Maximum Operating Frequency: | 300 MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.15@1mA@10mA|0.25@5mA@50mA V |
| Maximum Collector Base Voltage: | 160 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 625 mW |
| Mounting: | Through Hole |
| Rad Hard: | No |
| Type: | PNP |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 45 V |
| Maximum DC Collector Current: | 0.1 A |
| Minimum DC Current Gain: | 125@2mA@5V |
| Maximum Operating Frequency: | 100(Min) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.3@0.5mA@10mA|0.65@5mA@100mA V |
| Maximum Collector Base Voltage: | 50 V |
| Operating Temperature: | -65 to 150 ℃ |
| Maximum Power Dissipation: | 250 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
| Type: | NPN |
| Pin Count: | 3 |
| Maximum Collector Emitter Voltage: | 100 V |
| Maximum DC Collector Current: | 4 A |
| Minimum DC Current Gain: | 140@0.5A@5V |
| Maximum Operating Frequency: | 180(Typ) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.4@0.2A@2A V |
| Maximum Collector Base Voltage: | 120 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 1000 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
| Type: | NPN|PNP |
| Pin Count: | 6 |
| Maximum Collector Emitter Voltage: | 65 V |
| Maximum DC Collector Current: | 0.1 A |
| Minimum DC Current Gain: | 200@2mA@5V |
| Maximum Operating Frequency: | 100(Min) MHz |
| Maximum Collector Emitter Saturation Voltage: | 0.1@0.5mA@10mA V |
| Maximum Collector Base Voltage: | 80 V |
| Operating Temperature: | -55 to 150 ℃ |
| Maximum Power Dissipation: | 300 mW |
| Mounting: | Surface Mount |
| Rad Hard: | No |
